High-Performance Charge / Discharge Battery Testing System for Precise Battery Performance Analysis

High-Performance Charge / Discharge Battery Testing System for Precise Battery Performance Analysis
High-Performance Charge / Discharge Battery Testing System for Precise Battery Performance Analysis

Großes Bild :  High-Performance Charge / Discharge Battery Testing System for Precise Battery Performance Analysis

Produktdetails:
Herkunftsort: CHINA
Markenname: Haida
Zertifizierung: CE,,ISO
Modellnummer: 9007-HD
Zahlung und Versand AGB:
Min Bestellmenge: 1
Preis: Verhandelbar
Verpackung Informationen: Jeder Satz geschützt mit Harzfasern und PP -Film und dann mit Operation Man in eine starke hölzerne
Lieferzeit: 20 Tage nach Bestellung bestätigt
Zahlungsbedingungen: L/C, T/T, D/A, D/P, Western Union, Moneygram
Versorgungsmaterial-Fähigkeit: 300 Sätze pro Monat

High-Performance Charge / Discharge Battery Testing System for Precise Battery Performance Analysis

Beschreibung
Anwendung: Batterieprüfung Verdrahtungsmethode: AC-Drei-Phasen-Vierdraht
Anzeige: LCD Aktueller Bereich: 0-10A
Auflösung: 0,001 V/0,001a Verdrahtungsmethode: AC 220V
Genauigkeit: ± 0,1% Stromversorgung: AC
Hervorheben:

High Performance Charge Discharge Battery Testing System

,

Precise Charge Discharge Battery Testing System

 Series Partial Discharge Tester | IEC62368 G.5.4 Compliant High-Voltage PD Test System

Overview
The CS19010 Series is an advanced partial discharge tester designed for high-voltage insulation integrity evaluation in components such as optocouplers, magnetic couplers, IGBTs, MOSFETs, isolation substrates, and capacitors. This system performs precise partial discharge (PD) and withstand voltage tests, with a voltage output range of 0.1–10 kV and PD detection sensitivity from 1 pC to 10,000 pC. Complying with IEC62368 G.5.4, it serves as an essential tool for safety testing and quality assurance in both industrial and research environments.

Key Features

  • Dual-Function Testing: Combines partial discharge and withstand voltage testing in one instrument, with customizable high-voltage waveforms and judgment criteria.

  • Broad Compliance: Meets IEC62368 G.5.4, GB/T 7354-2018, IEC60270:2000, IEC60747-5-5, IEC60747-17, IEC60664-1, and IEC60747-15.

  • Precision Measurements: Covers leakage current from 0.01 µA to 1 mA and PD levels from 1 pC to 10,000 pC.

  • Programmable Operation: Allows adjustment of voltage ramp time (0.3–999.9 s), test duration, and PD detection delay.

  • Robust Performance: Operates reliably at 0–40°C and 15–95% RH with ≤1% waveform distortion.

  • Energy Efficient: Consumes ≤500 W, suitable for production and laboratory use.

Technical Specifications

  • Place of Origin: China

  • Brand: Kingpo

  • Certification: ISO9001, CE

  • Standard: IEC62368 G.5.4 (see document: IEC62368 G.5.4 Partial Discharge Tester.pdf)

  • Pulse Rate: 1–100 Hz

  • Power Supply: 220 VAC, 50/60 Hz

  • Calibration Capacitance: 5 pF, 10 pF, 100 pF

  • Dimensions & Weight:

    • Host: 426 × 136.5 × 527 mm, 22.5 kg

    • PD Test Module: 334 × 286 × 296.5 mm, 12 kg

Applications
Ideal for insulation performance validation in high-voltage isolation ICs, semiconductor devices, and insulating materials, ensuring compliance with international safety standards.

High-Performance Charge / Discharge Battery Testing System for Precise Battery Performance Analysis 0
Technical Specifications
Interface Parameter Range Tolerance
CVBS Brightness level 0–700 mV ±(2%X + 6 mV)
  Chromaticity level 0–885.1 mV ±3%
  Chroma phase 0–360° ±1°
YPbPr Luminance (Y) 0–700 mV ±(2%X + 6 mV)
  Color difference (Pb/Pr) -350–350 mV ±(2%X + 6 mV)
RF-ATV Level 70–120 dBμV ±3 dB
  Frequency 47–862 MHz 0.001%
RF-DTV Level -60–0 dBm ±2 dB
  Frequency 32–2196 MHz 0.0001%
  Modulation error ratio >36 dB
Testing Applications
  • TV energy efficiency testing

  • Set-top box testing

  • Monitor testing

Included Accessories

BNC cables, adapters, DP-HDMI converters

Product Tags

TV test equipment, AV test equipment, TV signal tester
