Infrared Water Vapor Permeability Tester for Packaging Materials

Infrared Water Vapor Permeability Tester for Packaging Materials
Infrared Water Vapor Permeability Tester for Packaging Materials Infrared Water Vapor Permeability Tester for Packaging Materials Infrared Water Vapor Permeability Tester for Packaging Materials Infrared Water Vapor Permeability Tester for Packaging Materials Infrared Water Vapor Permeability Tester for Packaging Materials Infrared Water Vapor Permeability Tester for Packaging Materials

Großes Bild :  Infrared Water Vapor Permeability Tester for Packaging Materials

Produktdetails:
Herkunftsort: China
Markenname: Haida
Zertifizierung: CE、ISO
Modellnummer: 5098-HD
Zahlung und Versand AGB:
Min Bestellmenge: 1 Set
Preis: Verhandelbar
Verpackung Informationen: Jedes Set ist mit Kunstharzfaser und PP-Folie geschützt und wird dann in einen stabilen Holzkasten m
Lieferzeit: 20 Tage nach Bestellbestätigung
Zahlungsbedingungen: L/C, D/A, D/P, T/T, Western Union, MoneyGram
Versorgungsmaterial-Fähigkeit: 300 Stück pro Monat

Infrared Water Vapor Permeability Tester for Packaging Materials

Beschreibung
Funktion: Druckprüfung name: Becherbecher-Rohr-Druckfestigkeitsprüfer, Papierprüfgerät Papier Grammatur-Tester/Berstfestigkeitspr
Anzeige: LCD,Digitalanzeige Einheiten umschalten: Kgf,N (Optional),Lbf
Anzeigemodus: LCD-Display, digitaler Modus Vibrationsmodus: Austauschen
Bewegungsantrieb: Kugelschraube und Servomotor Individuelle Unterstützung: OEM ODM
Verwendung: Papiertestgerät Eigenschaften: Hohe Präzision, einfache Bedienung, zuverlässige Leistung
Regler: PLC (Programmierbarer Logikcontroller) Falltest: Ecken, Kanten, Flächen der Probe
Anzeigeverfahren: Digitalanzeige Zeitanzeige: Zeit während der Prüfung (n) anzeigen
US-Bereich: Kochgeschirr Entwurfskriterien: EN71 ANSI, UL, ASTM ISTA
Steuerungssystem: PLC-programmierte Steuerung Ursprung: China
Prüfmethoden: Elektronische, mechanische, manuelle Gewicht: Anpassbar
Übertragungsart: Pneumatikvorrichtung + Reduzierstück + Freigabe Scanmodus: einzelne Zeile
Verwenden: Verpackungsmaterialien
Hervorheben:

Infrared Permeability Tester

,

Packaging Materials Vapor Permeability Tester

,

Packaging Materials Permeability Tester

EQUIPMENT DETAILS 5098-HD WATER VAPOR PERMEABILITY TESTER (INFRARED METHOD)
Product Specifications
Attribute Value
Function Compression test, Paper Tube Compressive Strength Test, Burst tester, Tensile test, Paper Testing Instrument
Display LCD, Digital display
Units switch Kgf, N. (Optional), Lbf
Control System PLC Programmed Control
Test Methods Electronic, mechanical, manual
Design Criteria EN71 ANSI, UL, ASTM ISTA
Features High precision, easy operation, reliable performance
Product Description
This infrared moisture analysis-based tester provides wide-range, high-efficiency water vapor transmission rate testing for medium and high water vapor barrier materials. It is suitable for testing plastic films, composite films, high barrier materials, backboards, sheets, paper, metal foils, and various packaging materials across industries including food, medicine, medical equipment, daily chemicals, and photovoltaic electronics.
Test Standards
GBT 26253, ISO 15106-2, ASTM F1249, TAPPI T557, JIS K7129, ISO 15106-3, DIN 53122-2, YBB 00092003
Key Features
  • Laser pulse modulated infrared sensor with long optical path absorption for higher measurement accuracy
  • Three independent test chambers for simultaneous testing of identical or different samples
  • Computer-controlled fully automated test process with one-button operation
  • High-quality components ensure instrument stability and reliability
  • Automatic test execution with parameter settings and result saving
  • Real-time test status monitoring with intelligent software for data analysis
  • Self-detection capabilities and power-off data storage protection
  • Precise automated temperature and humidity control for various test conditions
  • Multiple test process judgment modes (manual, proportional, cyclic)
  • Expandable test range for large transmittance testing requirements
Technical Specifications
Measuring range (membrane) 0.01~40 g/(m²*day) (standard)
0.1~1000 g/(m²*day) (optional)
Resolution 0.001 g/(m²*day)
Number of samples 1~3 pieces
Sample size φ110mm
Temperature control range 5℃~65℃ (constant temperature water bath)
Temperature control accuracy ±0.1℃
Humidity control range 0% RH, 5%~90%RH, 100%RH
Humidity control accuracy ±1%RH
Industry Applications
Haida products are extensively utilized across diverse industries including paper goods, packaging, ink printing, adhesive tapes, bags, footwear, leather goods, environmental protection materials, toys & baby products, hardware, electronics, plastics, and rubber. They comply with UL, ASTM, JIS, GB, and ISO standards.
Infrared Water Vapor Permeability Tester for Packaging Materials 0
Infrared Water Vapor Permeability Tester for Packaging Materials 1
Infrared Water Vapor Permeability Tester for Packaging Materials 2
